The TimeShift GUI, which enables users to develop custom waveforms, is available at an additional cost. A set of standard TimeShift waveforms is provided with each Quasar. For the Quasar UV80, UV60, UV60-Turbo and GR95 models, pulse widths from 100 ns can be created at a constant repetition rate or conversely, maintain constant pulse width with varying repetition rate from 0 to 3.5 MHz. TimeShift enables pulse width variation, as well as pulse splitting and burst mode operation. Utilizing TimeShift in conjunction with high UV or green power at a higher repetition rate means Quasar can process more materials faster, and with greater quality. By controlling the laser pulse (width and shape) in time and repetition rate, material removal and/or modification in micromachining becomes more efficient, thereby increasing process speed and quality. Quasar is the first laser of this class to offer TimeShift technology, which enables pulse energy programmability in the time domain. Quasar GR95 and GR75 dimensions noted do not include the standard removable lifting hoist exoskeleton or the optionally removable lift handles.Quasar GR95 and GR75: nominal pulse width is 10 ns.All green wavelength test specs are at 10 ns at 200 kHz with the diode current set to achieve 97 Watts for the Quasar GR95 and 77 Watts for the GR75.

Quasar rba skin#

Diffuse as well as specular reflections can cause severe skin or eye damage. Take precautions to prevent exposure to the direct and reflected beams.

Quasar is a Class IV - High Power Laser, whose beam is, by definition, a safety and fire hazard.

Quasar UV80, UV60, UV60-Turbo and UV45 dimensions noted do not include the standard removable lifting hoist exoskeleton or the optionally removable lift handles.

Contact Spectra-Physics for more information. Alternative/programmable pulse widths using TimeShift will change power and beam parameter performance. Quasar UV60-Turbo nominal and pulse width is 2 ns.

Quasar UV80, UV60 and UV45: nominal pulse width 10 ns.

Quasar UV60-Turbo test specs are at 3 MHz 2 ns with diode current set to achieve 40 W.

Quasar UV60 and UV45 nm test specs are at 10 ns at 300 kHz with the diode current set to achieve 62 W for the Quasar UV60, and 42 W for the UV45. Quasar UV80 nm test specs are at 10 ns at 200 kHz with the diode current set to achieve 81 W.Due to our continuous product improvement program, specifications may change without notice.Long and short term recording for diagnostics and equipment maintenance Maximum Pulse Energy or Burst Energy at Optimization Pointġ90–240 VAC, 2500 Watts Maximum, 50/60 Hz, single phaseģ9.4 x 14.7 x 9.3 in (1000 x 373 x 235 mm)Ģ1.1 x 19.0 x 6.9 in (536 x 483 x 176 mm)ĭata Log (includes customer version as well)
